Products

DESCRIPTION

Basic Info

Model NO.	BEAMFLEX
Beam Angle	13°/25°/45°
Lifespan	50000 hours
Warranty	5 Years
Certification	CE, RoHS
Electric Current Type	DC
Input Voltage	24V
CCT	3000K/4000K/6500K
CRI	90
Working Lifetime	50000h
LED Quantity	56/112/126LED/M
Width	12mm
Sdcm	≤5-Step
LED Chip Brand	Sanan
LED Chip	SMD2835
Ambient Temperature	-20 … + 40°c
Operating Temperature	-20 … + 80 °c
Storage Temperature	-35 … + 80°c
Transport Package	Inner Box and Carton
Specification	5 meter/reel
Trademark	OEM&ODM
Origin	Shenzhen, China
HS Code	9405409000
Production Capacity	50000meters/Days

Packaging & Delivery

Package size per unit product 100.00cm * 1.00cm * 1.00cm Gross weight per unit product 0.500kg

Product Description

Features:
1. Can Achieve Great Wall Washing / Wall Grazing Effects2. Structural Patent Technology3. Silicone Extrusion Technology4. RTR (R2R, Roll to Roll) Manufacturing Process5. 5 Years Warranty6. Dimmable & Tunable(3000K-6500K)7. Optic Lens:13°x50, 25°X55, 45°X55 in Available

Wall Grazer Light Talk:
Wall grazing lights is a technique that the lights are positioned close to the wall so that the beam angle will hit the wall at a narrow angle and achieve a uniform effect. It can create a dramatic lighting effect and draw the attentions, especially when grazing a textured wall. The details of the wall can be accentuated.

And at the same time, it could minimize the glare when people directly view the lighting fixture.
Parameter

V/DC	24V	PCB Material	2ounces Double Layer Copper FPC
POW.	17W	PCB Width	12mm
Light Color	Static-White/Dynamic-White	Copper Width	2oz
CCT	3000K/4000K/6500K	Adhesive Tape	3M VHB 300LSE
CRI	90	LED Chip Brand	San'an
Beam Angle	13°×50°/25°×55°/45°×55°	Storage Temperature	-35...+80ºC
SDCM	3-step	Ambient Temperature	-20...+45ºC
IP Rating	IP66	Waterproof Level	Waterproof
Cutting Unit(mm)	125mm	Certification	CE/RoHS
Warranty	5 years	Photobiological Safety	IEC 62471
LED Source	SMD LED	Ingress Protection	EN 60529
LED Quantity	56 LEDs/M / 112LEDs/M	Safety Requirement	EN 62031 IEC 60598-1
Package	5 meters/reel	EMC/Radio Disturbance Characteristics	EN 55015

Features & DetailsPARAMETER SPECIFICATIONHIGH QUALITY SILICONE RUBBER WITHOUT YELLOWING The light strip is fully-wrapped by food grade silicone material which is more flexible and has higher waterproof effect, better resistance to weather and corrosion, more prominent anti-UV ability than traditional PVC jacket. It can be used in outdoor environment. It could be exposed to direct sunlight for a long time, but will not be yellowing and aging.ABOUT US
